satellite receiver dvb-s2 16 input rf 16 ip mpts output . 16 entradas dvb-s2 16 numeros de ip output
- Product Code: dvb-s2 16 rf input
- Availability: Out Of Stock
Satellite receiver dvb-s2 16 input rf 16 ip mpts output . 16 entradas dvb-s2 16 numeros de ip output.
Receptor de satelite con 16 rf entradas dvb-s2 y salida 16 direciones de ip.MPTS varios canales por cada numero de ip.
Technical Specification
Input
16×RF
16×F-head
Demodulation Mode
DVB-S/S2
Symbol Rate
1~45Mbaud/s
Frequency Range
950MHz~2150MHz
Error Correction Coding
RS coding 188/204
Output
2×ASI
DVB standard, BNC interface
Output LEV
≥115dBmV
Impedance
75Ω
Output Return Loss
≥12 dB
Control
NMS (Ethernet port, RJ-45), Keyboard + LCD
General Features
Size
482mm×280mm×44mm
Temperature Range
0~45°C (Operation); -20~80°C (Storage)
Power
100-240VAC, 50Hz, 25W
